Allen Bradley 1756-WS ControlLogix Weigh Scale Module

Descripción

Description

The 1756-WS module reads weight and diagnostic data from strain gauge load sensors or load cells and transmits this information via the ControlLogix backplane. It provides high-resolution weight measurement, ensuring accurate and reliable process control.

Specifications

• Model: 1756-WS

• Type: Single-slot weigh scale module

• Resolution: Over 8 million counts

• Update Rate: 50 times per second

• Excitation Voltage: 5V DC (supports up to four 350-ohm load cells)

• Communication: Producer/consumer technology for real-time data exchange

• Operating Temperature: 0°C to 60°C

Features

• High Accuracy: Provides precise weight measurement with minimal signal noise.

• Integrated Calibration: Supports C2® electronic calibration, eliminating the need for test weights.

• Vibration Filtering: Uses WAVERSAVER® technology to ignore environmental vibrations.

• Hot-Swappable: Can be removed or inserted under power without disrupting operations.

• Diagnostic LEDs: Offers real-time status monitoring for troubleshooting.
