Schneider Electric 140AMM0900 Analog Input/Output Module

Descripción

Description

The 140AMM0900 module provides four analog inputs and two analog outputs, supporting various voltage and current ranges. It features high-resolution signal conversion, ensuring accurate data acquisition and control in demanding environments.

Specifications

• Series: Modicon Quantum

• Number of Inputs: 4 analog inputs

• Number of Outputs: 2 analog outputs

• Input Types:

  • Bipolar current: ±20 mA (15-bit resolution)

  • Bipolar voltage: ±10 V (16-bit resolution)

  • Bipolar voltage: ±5 V (15-bit resolution)

  • Unipolar current: 0-20 mA (15-bit resolution)

  • Unipolar voltage: 0-10 V (16-bit resolution)

  • Unipolar voltage: 0-5 V (15-bit resolution)

• Output Type: 4-20 mA (12-bit resolution)

• Loop Voltage: 0-60V DC (with external resistance)

• Operating Temperature: 0°C to 60°C

• Isolation Voltage: 500V AC / 750V DC (channel-to-channel and bus isolation)

Features

• High Accuracy: Provides precise signal conversion with minimal error.

• Wide Input Range: Supports multiple voltage and current configurations.

• Industrial-Grade Durability: Designed for harsh environments with robust electrical isolation.

• Diagnostic LEDs: Offers real-time status monitoring for troubleshooting.

• Fast Response Time: Ensures efficient signal processing for automation systems.
